Probe
P605 Probe Series
A very fine, short travel, push fit battery contact test probe.
Due to its small pitch, it is suitable for applications with limited space.
A wire wrap receptacle is also available.
Product specification
| Mil | 50 |
| Centres | 1.27 mm |
| Full Travel | 1.20 mm |
| Working Travel | 0.80 mm |
| Current Resistance | 4.00 amps |
| Continuity Resistance | 70.00 mOhms |
| Product Series | P605 |
| Application | Battery Contact |
| Solutions | Short Travel Testing |
Request for quote
Please choose your Head Diameter and/or Head style to select Probes. The suitable part numbers are then shown below our head style images.
