HSP8611/G High Current Probe Series (400 amps)
High current probe for testing of EV connectors.
Configured with 9 high current probes and sense pin for voltage sensing.
Capable of handling 400 amps.
M10 thread.
Product specification
| Centres | 25.00 mm |
| Full Travel | 5.50 mm |
| Working Travel | 4.40 mm |
| Current Resistance | 400.00 amps |
| Continuity Resistance | 5.00 mOhms |
| Application | High Current Screw In Test Heads |
| Solutions | Battery & High Current Testing EV Connector Testing Wire Harness Testing |
Request for quote
Please choose your Head Diameter and/or Head style to select Probes. The suitable part numbers are then shown below our head style images.
