HSP25 High Current Probe Series

High current ATE push fit test probe.

This probe has a 8 amp current as standard. (*Head styles A. B & C are available with a 10 amp specification)

Please contact us for further information and availability

This probe is compatible with standard R25 receptacles.

Please see series P25 for a standard current of 5 amps.

Mil	100
Centres	2.54 mm
Full Travel	6.35 mm
Working Travel	4.24 mm
Current Resistance	8.00 amps
Product Series	HSP25
Application	High Current ICT/FCT
Solutions	Battery & High Current Testing PCB & ATE Testing

Please choose your Head Diameter and/or Head style to select Probes. The suitable part numbers are then shown below our head style images.

Part Number	Head Diameter	Working Travel Spring Force	Head Style
HSP25-H	1.50 mm	1.80 N	Chisel - H
HSP25-C	1.50 mm	1.80 N	Serrated - C
HSP25-B	0.90 mm	1.80 N	Spear - B
HSP25-A	1.50 mm	1.80 N	Concave - A
HSP25-Q	1.30 mm	1.80 N	4 Point Crown - Q
